Product Overview
MAIN FEATURES:
12CH synchronized A/V recording and playback (8CH AHD 1080P + 4CH IPC)
8 x 1080P AHD + 4CH IPC
Support 2*4TB HDD and 1*512GB SD card
Internal G-Sensor, GPS/3G/4G/5G/WIFI Optional
Support 1*USB (mouse operation)
Onboard UPS 8 seconds delay power-off for data protection
8V-36V wide voltage power supply
SPECIFICATIONS:
|
Operating Language
|
Simplified Chinese, Traditional Chinese, Russian, English, Korean, Japanese
|
|
Main Processor
|
HiSilicon Hi3520DV400
|
|
Operating System
|
Embedded Linux-3.10.Y operating system
|
|
Password Permissions
|
administrator, user rights
|
|
Operation Interface
|
Graphical menu operation interface, mouse operation menu interface
|
|
Image Format
|
1080P/720p/960H/D1/HD1/CIF optional
|
|
Video Streaming Standard
|
ISO14496-10
|
|
Video Format
|
PAL, NTSC
|
|
Screen Display
|
1.2.4.6.8.9.12 Screen Display
|
|
Video Compression
|
H.265
|
|
Audio Compression
|
G.726 format
|
|
Recording Method
|
Audio and video simultaneous recording
|
|
Video Query
|
Search by recording type and alarm type
|
|
Storage Medium
|
Dual hard disk + SD card, hard disk supports 2 4TB, SD card supports up to 512 GB
|
|
Upgrade Method
|
local upgrade, remote upgrade
|
|
Output Signal
|
VGA/AV
|
|
Support Signal
|
8CH 1080P+4CH IP CAMERA signal input
|
|
Input Power
|
DC 12-36V power input
|
|
Output Power
|
DC 12V 1000MA
|
|
Operating Temperature
|
‘-25℃ - +85℃
|
|
Rs232/485
|
Supports 2 groups of 232 inputs and 1 group of 485 inputs
|
|
Alarm Input
|
Support 8 alarm inputs, 2 groups of alarm outputs
|
